Skeo TT
6Y42
Stabilises during wear, flexible when walking
The distal matrix of the Skeo liner has a length of 10 cm and prevents lengthwise stretching. It gives the user good control over the prosthesis and a high level of safety. At the same time, the Skeo lower leg liner easily adapts to slight fluctuations in volume thanks to its transverse elasticity.
The distal matrix of the Skeo liner has a length of 10 cm and prevents lengthwise stretching. It gives the user good control over the prosthesis and a high level of safety. At the same time, the Skeo lower leg liner easily adapts to slight fluctuations in volume thanks to its transverse elasticity.
The 6Y42 Skeo (TT) can be combined with a shuttle lock.
| Product type | Locking |
| Amputation level | Transtibial amputation |
| Material | Silicone |
Specifications
Product information
| Product type | Locking |
| Amputation level | Transtibial amputation |
| Material | Silicone |
Product Data
| Amputation level | Transtibial amputation | ||||||
| Material | Silicone | ||||||
| Connection | With distal connection | ||||||
| Distal cushion | 13.5 mm | ||||||
| Wall thickness | from approx. 4.5 mm distally, tapering to 2.5 mm proximally | From 4.5 mm distally, tapering to 2.5 mm proximally | from approx. 4.5 mm distally, tapering to 2.5 mm proximally | From 4.5 mm distally, tapering to 2.5 mm proximally | from approx. 4.5 mm distally, tapering to 2.5 mm proximally | From 4.5 mm distally, tapering to 2.5 mm proximally | from approx. 4.5 mm distally, tapering to 2.5 mm proximally |
| Textile cover | with | ||||||
| Colour | Light grey | ||||||
| Exterior coating | without | ||||||
| Socket design | Specific weight-bearing socket | ||||||
| Matrix | 10 cm length | ||||||
| Skinguard | without |
| Article number | Size |
|---|---|
| 6Y42=180 | 180 mm |
| 6Y42=200 | 200 mm |
| 6Y42=210 | 210 mm |
| 6Y42=220 | 220 mm |
| 6Y42=235 | 235 mm |
| 6Y42=250 | 250 mm |
| 6Y42=265 | 265 mm |
| 6Y42=280 | 280 mm |
| 6Y42=300 | 300 mm |
| 6Y42=320 | 320 mm |
| 6Y42=340 | 340 mm |
| 6Y42=360 | 360 mm |
| 6Y42=380 | 380 mm |
| 6Y42=400 | 400 mm |
| 6Y42=420 | 420 mm |
| 6Y42=450 | 450 mm |
