The Juvo product range

Enhance life, demand quality

While developing the Juvo product range in cooperation with therapists and users, we placed great emphasis on individual components that can be combined with one another in a flexible manner. The modular design of the power wheelchairs offers almost boundless possibilities – from the basic model to the high-end version. Design, ease of service and functionality were key as well.

While developing the Juvo product range in cooperation with therapists and users, we placed great emphasis on individual components that can be combined with one another in a flexible manner. The modular design of the power wheelchairs offers almost boundless possibilities – from the basic model to the high-end version. Design, ease of service and functionality were key as well.

Three types of drives – front-wheel, mid-wheel and rear-wheel drive – are available with specific driving characteristics and motor powers in two frame widths.

Crash test approved!

From £3,879 (RRP)







Max. body weight200 kg
ActivitiesRehab
User groupmen, women, adults, mature adults, youth
All specifications
Benefits at a glance
    Ottobock TEN° control device for the Juvo power wheelchair
    Control devices

    The quality and user friendliness of a chosen control device not only determine your comfort when driving the power wheelchair but also set all the parameters for your everyday independence. A variety of basic, attendant, special and environmental controls are available for the Juvo. We are happy to advise you!

    User Pierre in his Juvo power wheelchair from Ottobock chilling in a port cafe.
    The right seat

    Seating solutions are as individual as every user, and they have to be considered this way, too. This is why we offer various modules that can be combined with one another. The variable adaptable seat (VAS) is one possible seating solution. It is precisely adapted to the individual measurements by the specialist dealer. The Baxx back support system and the contour package are other available seating solutions.

    Close-up, side of the Juvo with LED lighting.
    Magnetic LED lighting

    The magnetic holder for the LED lighting makes it easy to attach and remove the lighting without the use of tools. If the wheelchair requires servicing, the LED lighting can be removed and conveniently used like a torch.

    Ottobock Juvo quick mobile service
    Quick mobile service

    Should repairs be required, you don’t have to go without the custom seat you’re used to. The chassis and seat can be easily separated, making it simple to replace the drive unit and battery.

    Juvo user Anja driving her Juvo out of a car
    Extended mobility

     Whether in a vehicle for transporting persons with reduced mobility, using the Dahl docking system as a passenger or behind the wheel – the Juvo is ISO certified and a reliable travel partner.

User Experience

Balancing family and a love of volunteering

When people hear what her day-to-day life involves, they can’t believe Anja is able to balance all these responsibilities. Aside from managing her small family and running the household, she handles a variety of consulting and care assignments on a volunteer basis. But the wife and mother from Chemnitz, who has had a progressive neuromuscular disease since childhood, doesn’t even consider it worth mentioning. She owes a great deal of her flexibility to the Juvo power wheelchair, which she was able to adapt to her specific needs and requirements. “Before, I had to ask for help to hang out the laundry or reach higher shelves in the supermarket. Now I can adjust my seat to the height I need.” The manoeuvrability of the Juvo and its narrow width, which lets her negotiate tight
corridors, is a big plus, especially in labyrinthine doctor’s and therapy practices. “I prefer to spend the time I save that way with my son Pascale in his favourite museum.” She relies on the mid-wheel drive she selected on these trips. “I first had the chance to test this drive type during rehabilitation and loved it straightaway.” Since Anja has a rather rare form of her disease, she doesn’t know what the future holds. Her Juvo will definitely be part of it, helping her make the best of each day with her family’s support.

Functionality

Frontantrieb

Aufgrund seiner großen Antriebsräder bietet der Juvo eine gute Hindernisüberwindung. Außerdem eröffnet er gute Transfer- und Rangiermöglichkeiten. Er verfügt über einen kleinen Wenderadius und über die Fähigkeit, besonders nah an Objekte heranzufahren.

Specifications

Product information

Max. body weight200 kg
ActivitiesRehab
User groupmen, women, adults, mature adults, youth
ColourGrey, Black, Orange, Red, Green, White, Blue, Yellow
Speed(s)6 km/h, 10 km/h, 14 km/h
Number of power seat adjustments
Max. load200 kg
Scope of applicationMobility
Product typePower wheelchairs

Product Data

DescriptionJuvo ALL masterJuvo RWD masterJuvo FWD masterJuvo MWD master
Seat width340 – 560 mm340 – 560 mm340 – 560 mm340 – 560 mm
Seat height410 - 570 mm410 - 570 mm410 - 570 mm410 - 570 mm
Seat depth340 – 580 mm340 – 580 mm340 – 580 mm340 – 580 mm
Back angle30°30°30°30°
Seat tilt45° power45° power45° power45° power
Arm support height200 – 400 mm200 – 400 mm200 – 400 mm200 – 400 mm
Lower leg length150 – 540 mm150 – 540 mm150 – 540 mm150 – 540 mm
Battery capacity56 Ah (C5) / 60,4 Ah (C20) AGM, 63 Ah (C5) / 75 Ah (C20) AGM, 63 Ah (C5) / 74 Ah (C20) Gel56 Ah (C5) / 60,4 Ah (C20) AGM, 63 Ah (C5) / 75 Ah (C20) AGM, 63 Ah (C5) / 74 Ah (C20) Gel56 Ah (C5) / 60,4 Ah (C20) AGM, 63 Ah (C5) / 75 Ah (C20) AGM, 63 Ah (C5) / 74 Ah (C20) Gel56 Ah (C5) / 60,4 Ah (C20) AGM, 63 Ah (C5) / 75 Ah (C20) AGM, 63 Ah (C5) / 74 Ah (C20) Gel
Max. charging timemax. 12 hmax. 12 hmax. 12 hmax. 12 h
Max. driving distance range (according to ISO 7176-4)Approx. 45 kmApprox. 45 kmApprox. 45 kmApprox. 45 km
Climbing ability10°/17%10°/17%10°/17%10°/17%
Turning radius750 mm965 mm750 mm750 mm
Weight when empty120 kg120 kg120 kg120 kg
