Uneo 3D

An intelligent fit for maximum comfort: the Uneo 3D is precisely adapted to the anatomy of the residual limb. Sensitive areas such as the edge of the shin and head of the fibula are protected by thicker walls. Meanwhile, thinner walls at the rear improve knee mobility.The 6Y512 Uneo (TT) can be combined with the valve or the Harmony system.

6Y512 - Liners

Uneo 3D

Gentle cushioning effect, anatomical shape for improved comfort

An intelligent fit for maximum comfort: the Uneo 3D is precisely adapted to the anatomy of the residual limb. Sensitive areas such as the edge of the shin and head of the fibula are protected by thicker walls. Meanwhile, thinner walls at the rear improve knee mobility.The 6Y512 Uneo (TT) can be combined with the valve or the Harmony system.

Product typeCushion
Amputation levelTranstibial amputation
MaterialPolyurethane

Uneo 3D

An intelligent fit for maximum comfort: the Uneo 3D is precisely adapted to the anatomy of the residual limb. Sensitive areas such as the edge of the shin and head of the fibula are protected by thicker walls. Meanwhile, thinner walls at the rear improve knee mobility.The 6Y512 Uneo (TT) can be combined with the valve or the Harmony system.

Specifications

Product information

Product typeCushion
Amputation levelTranstibial amputation
User groupwomen, men, adults, elderly
MaterialPolyurethane
Distal connectionwithout

Product Data

Article numberSizeResidual limb length below the MPTSkinguardTextile coverColor
6Y512=250X75-G9.84″ (10.04″-10.83″)2.95″ (1.97″-3.94″)withwithoutTransparent
6Y512=210X125-G8.27″ (8.46″-925″)4.92″ (3.94″-5.91″)withwithoutTransparent
6Y512=235X125-G9.25″ (9.45″-10.43″)4.92″ (3.94″-5.91″)withwithoutTransparent
6Y512=265X125-G10.43″ (10.24″-11.02″)4.92″ (3.94″-5.91″)withwithoutTransparent
6Y512=280X125-G11.02″ (11.22″-12.20″)4.92″ (3.94″-5.91″)withwithoutTransparent
6Y512=300X125-G11.81″ (12.2″-13.19″)4.92″ (3.94″-5.91″)withwithoutTransparent
6Y512=210X175-G8.27″ (8.46″-925″)6.89″ (5.91″-7.87″)withwithoutTransparent
6Y512=235X175-G9.25″ (9.45″-10.43″)6.89″ (5.91″-7.87″)withwithoutTransparent
6Y512=265X175-G10.43″ (10.24″-11.02″)6.89″ (5.91″-7.87″)withwithoutTransparent
6Y512=280X175-G11.02″ (11.22″-12.20″)6.89″ (5.91″-7.87″)withwithoutTransparent
6Y512=300X175-G11.81″ (12.2″-13.19″)6.89″ (5.91″-7.87″)withwithoutTransparent
6Y512=250X75-F-G9.84″ (10.04″-10.83″)2.95″ (1.97″-3.94″)withwithAnthracite
6Y512=210X125-F-G8.27″ (8.46″-925″)4.92″ (3.94″-5.91″)withwithAnthracite
6Y512=235X125-F-G9.25″ (9.45″-10.43″)4.92″ (3.94″-5.91″)withwithAnthracite
6Y512=265X125-F-G10.43″ (10.24″-11.02″)4.92″ (3.94″-5.91″)withwithAnthracite
6Y512=280X125-F-G11.02″ (11.22″-12.20″)4.92″ (3.94″-5.91″)withwithAnthracite
6Y512=300X125-F-G11.81″ (12.2″-13.19″)4.92″ (3.94″-5.91″)withwithAnthracite
6Y512=210X175-F-G8.27″ (8.46″-925″)6.89″ (5.91″-7.87″)withwithAnthracite
6Y512=235X175-F-G9.25″ (9.45″-10.43″)6.89″ (5.91″-7.87″)withwithAnthracite
6Y512=265X175-F-G10.43″ (10.24″-11.02″)6.89″ (5.91″-7.87″)withwithAnthracite
6Y512=280X175-F-G11.02″ (11.22″-12.20″)6.89″ (5.91″-7.87″)withwithAnthracite
6Y512=300X175-F-G11.81″ (12.2″-13.19″)6.89″ (5.91″-7.87″)withwithAnthracite
6Y512=250X759.84″ (10.04″-10.83″)2.95″ (1.97″-3.94″)withoutwithoutTransparent
6Y512=210X1258.27″ (8.46″-925″)4.92″ (3.94″-5.91″)withoutwithoutTransparent
6Y512=235X1259.25″ (9.45″-10.43″)4.92″ (3.94″-5.91″)withoutwithoutTransparent
6Y512=265X12510.43″ (10.24″-11.02″)4.92″ (3.94″-5.91″)withoutwithoutTransparent
6Y512=280X12511.02″ (11.22″-12.20″)4.92″ (3.94″-5.91″)withoutwithoutTransparent
6Y512=300X12511.81″ (12.2″-13.19″)4.92″ (3.94″-5.91″)withoutwithoutTransparent
6Y512=210X1758.27″ (8.46″-925″)6.89″ (5.91″-7.87″)withoutwithoutTransparent
6Y512=235X1759.25″ (9.45″-10.43″)6.89″ (5.91″-7.87″)withoutwithoutTransparent
6Y512=265X17510.43″ (10.24″-11.02″)6.89″ (5.91″-7.87″)withoutwithoutTransparent
6Y512=280X17511.02″ (11.22″-12.20″)6.89″ (5.91″-7.87″)withoutwithoutTransparent
6Y512=300X17511.81″ (12.2″-13.19″)6.89″ (5.91″-7.87″)withoutwithoutTransparent
6Y512=250X75-F9.84″ (10.04″-10.83″)2.95″ (1.97″-3.94″)withoutwithAnthracite
6Y512=210X125-F8.27″ (8.46″-925″)4.92″ (3.94″-5.91″)withoutwithAnthracite
6Y512=235X125-F9.25″ (9.45″-10.43″)4.92″ (3.94″-5.91″)withoutwithAnthracite
6Y512=265X125-F10.43″ (10.24″-11.02″)4.92″ (3.94″-5.91″)withoutwithAnthracite
6Y512=280X125-F11.02″ (11.22″-12.20″)4.92″ (3.94″-5.91″)withoutwithAnthracite
6Y512=300X125-F11.81″ (12.2″-13.19″)4.92″ (3.94″-5.91″)withoutwithAnthracite
6Y512=210X175-F8.27″ (8.46″-925″)6.89″ (5.91″-7.87″)withoutwithAnthracite
6Y512=235X175-F9.25″ (9.45″-10.43″)6.89″ (5.91″-7.87″)withoutwithAnthracite
6Y512=265X175-F10.43″ (10.24″-11.02″)6.89″ (5.91″-7.87″)withoutwithAnthracite
6Y512=280X175-F11.02″ (11.22″-12.20″)6.89″ (5.91″-7.87″)withoutwithAnthracite
6Y512=300X175-F11.81″ (12.2″-13.19″)6.89″ (5.91″-7.87″)withoutwithAnthracite
Amputation levelTranstibial amputation
MaterialPolyurethane
Connection

Without distal connection

Distal cushion0.59 ″
Wall thickness0.35″ build-ups at the tibial crest and fibular head, from 0.24″ distally, tapering to 0.12″ proximally
Exterior coatingwithout
Socket designTotal surface weight-bearing socket
Matrixwithout
Downloads

Documents

Instructions for use
6Y512Instructions for use

647G380=ALL_INT

Instructions for use | Liner
Download (Deutsch, English, Français, Italiano, Español, Nederlandse, Svenska, Polszczyzna, Magyar nyelv, Čeština, Românesc, Hrvatski, Slovenský, Български, Türkçe, Русский, 日本語, 한국말, PDF 1 MB) Instructions for use
6Y512Instructions for use

647G1144=ALL_INT

Instructions for use | Liner
Download (Deutsch, English, Français, Italiano, Español, Nederlandse, Svenska, Polszczyzna, Magyar nyelv, Čeština, Românesc, Hrvatski, Slovenský, Български, Türkçe, Русский, 日本語, 한국말, PDF 1 MB) Instructions for use
Declaration of conformity
6Y512Declaration of conformity

4179913

Declaration of Conformity for 6Y510 6Y512 6Y520 6Y522 6Y523 6Y400 6Y402 6Y404 6Y416 6Y417 6Y418 6Y430 6Y432 6Y434 6Y470
Download (PDF 1 MB) Declaration of conformity
